KT-120M

$2,058.50 including GST

Description

Sonel KT-120M is a special camera. Economical, practical and handy, it is a powerful tool in preventing or limiting epidemics.

The user can measure the temperature with 0.5°C accuracy. The exceeding of the threshold value is signalled by an alarm. All this in order to quickly and efficiently detect people with fever – e.g. infected with a virus giving such symptoms.

Sonel KT-120M is used wherever many people need to be tested for body temperature. Particularly useful in:

  • factories,
  • schools,
  • shopping malls,
  • office buildings.

Videos

More news coming soon

Courses Coming Up Soon

Like us on Facebook or subscribe to our Blog to stay up to date with upcoming training courses.

More Details

Features

  • measuring range 20°C…50°C
  • accuracy up to ±0.5°C
  • fast temperature measurement
  • automatic signalling of fever detection
  • saving IR images to SD card or directly to a PC
  • built-in Li-Ion battery with 8-hour working time
  • interfaces: microUSB 2.0 type C, SD slot
  • can be set up on a tripod

Specifications

Detector resolution120 x 90 / 17 μm
Detector7.5~14 μm
Frame rate25 Hz
Sensitivity60 mK
Lens (field of vision / focal distance)50° x 38°/2.28 mm
Spatial resolution (IFOV)7.6 mrad
Display2.4″, 240 x 320, LCD
Image modeIR
Temperature range20°C…50°C
Accuracy≤0.5°C
(ambient temperature 25°C, target distance 1 m,
target temperature 32°C…42°C)
Image analysis modeTemperature indication,
temperature alarm – color
Emissivity
Measurement pointCentral
Image file formatJPG
InterfacesmicroSD card slot (max. 32 GB),
microUSB 2.0 type C, tripod
MemorySD card (max. 32 GB)
Power supplyLi-Ion battery (operating time >8 hours),
built-in charger (charging time <2.5 hour),
AC adapter 110-230 V, 50/60 Hz
Operating temperature-10°C…+50°C
Storage temperature-40°C…+70°C
HousingIP54
Weightca. 0.35 kg
