Description
Features
- Fully programmed operation
- Accurate digital read out of tripping time and Current
- 450ms readout for testing latest delay action breakers
- Two LED lamps give quick check for correct wiring
- Compact, lightweight and simple to operate
- Zero cross circuitry permits testing at 0° and 180° portion of sine wave
Size(HxWxD): 200mm x 70mm x 45mm
Weight: 253g
| Specifications | |
| Operational voltage | 195V – 253V /45 – 65Hz |
| Trip current settings | 10mA, 30mA, 100mA, 300mA, 500mA, 650mA |
| Trip current measurement accuracy | ±10% ±2digits |
| Trip time ranges | 0ms – 300ms |
| Trip time accuracy | ±5% ±3digits |
| Ramp test | x0.4 to 1.1 times nominal rated current, accuracy±10 % |
